LC79 Waterproof Metal Gear Digital Servo Upgrade

Features:

• High-performance digital standard for precise control
• Low noise operation with extended service life
• Compact design delivering high torque output
• Suitable for RC cars, boats, and helicopter models

Specifications:

Operating Voltage : 4.8~6.0V DC
Max. Torque : 9kgf·cm
No Load Speed : 4.8V≤0.10sec/60°; 6.0V≤0.12sec/60°
Stall Current:4.8V≦1500mA;6.0V≦1800mA
Consumption Current* (No Load):4.8V ≦200mA ;6.0V≦210mA
Max. Operating Travel Angle:180°±10°(1000~2000μs)
Dead Band Width: ≤ 1us
Mechanical Limit Angle: 360°
Communication Interface: PWM
Motor Type: Core motor
Case Material: ABS
Gear Set Material : Metal gear
Weight: 20.7 g
Size: 29.6 × 13.2 × 40mm
